You Supply Your Schematic and BOM and We Do The Rest!



PCB Design Services:

  • Schematic Capture  Symbol Creation
  • Create Custom Component Footprint
  • PCB Form and Fit Design
  • PCB Layout Design
  • Prototype PCB/Assembly Procurement
  • General design capabilities include high-speed digital, analog and mixed-signal, ultra-high density boards, package design, and RF.
  • UL/CE Spacing and Creepage
  • High-speed Signal Design
  • Differential Impedance Control
  • Fine Pitch BGA Layout
  • High Current/Voltage Designs
  • 3D Models
  • Design for Manufacturability
  • Design for Testability

Get Your Quote Now
